Product Detail:

Feature

Contact Ratings

Contact Form 1Z

Contact circuit Voltage and loading current(resistant) 48VDC Max 50A

Contact Resistance 30mΩMax.

20±5oC cold state max motion voltage(VDC) Pick-up 70%

Drop-out 5%~30%

Machanical life(Min.) 100,000 Ops

Electrical life(Min.) 50,000 Ops

Coil Ratings

Coil rated voltage 12~48 VDC

Max coil current under the rated voltage 0.15A

With 20±5oC cold state starting coil max current 5A

Specification

Insulation Resistance 100MΩMin.

Dielectric strength Between Contacts 2000VAC.

Between coil and contacts 1500VAC.

Environment temperature and attitude -60oC~+70oC; 0~20000m

Max relative humidity 98%

The shocking of fixed point Frequency(11Z) 10~200

Acceleration(g) ≤3.5

Shocking Speed(time/min.) 60~100

Acceleration(g) 4

Constant acceleration 8

Operation regulation(Continue)

Installation direction(Random)

Layout (Bottom view)
