AMC2-244 thru AMC2-252 2 pole contactors(30A thru 40A)
Product Detail:
Designed for air conditioning and heating equipment
Features
1.Low VA coil for cooler operation and increased life.
2.Quiet operation
3.Universal style mounting bracket fits existing mounting holes.
4. Double break contacts ensure positive make and break.
5. Screw terminals or pressure connectors and double 1/4 quick connects provided on all models for easy installation
Specifications
| Insulating material | Contact block and carrier are high quality electrical-grade thermosetting resin |
| Temperature range | -40oF to 150oF |
| Mechanical life (no load) | Conforms to UL and ARI specifications |
| Electricl life | Conforms to UL and ARI specifications |
| Weight (approximate) | 9.25 oz |
| Coils Frequency | 50/60Hz |
| Coil insulation | Class B(130oC) |
| Termination | Pressure connector and double 1/4 Q.C |
| Operate | 85%of nominal coil coltage; 110% maximum safe operate |
| Duty cycle | Continuous |
Coil data
|
Steveco Number 30 Amp 40Amp |
Voltage AC | Ress DC OHMS | Current MA | Nominal VA | Max. inrush |
| AMC2-244 AMC2-247 | 24 | 11 | 250 | 6 | 32 |
| AMC2-245 AMC2-248 | 120 | 224 | 50 | 6 | 32 |
| AMC2-246 AMC2-249 | 208/240 | 997 | 25 | 6 | 32 |
Contact ratings
| Type | Voltage | FLA | LRA | RES |
| AMC2-244 thru AMC2-246 | 277 | 30 | 150 | 40 |
| 480 | 30 | 75 | 40 | |
| 600 | 30 | 50 | 40 | |
| AMC2-247 thru AMC2-252 | 277 | 40 | 200 | 50 |
| 480 | 40 | 100 | 50 | |
| 600 | 40 | 80 | 50 |
