CJX9 Air Condition AC
Product Detail:
1.Application
This series contactor is mainly applicable to a line of AC 50Hz or 60Hz, rated working voltage up to 600V and rated working current up to 60A, used to close or and to switch off the line. It complies to IEC947-4-1.
2.Specification
| P/N | AMPS | VOLTS |
| CJX9-2S-30-24V | 30 | 24 |
| CJX9-2S-30-120V | 30 | 120 |
| CJX9-2S-30-240V | 30 | 240 |
| CJX9-2M-40-24V | 40 | 24 |
| CJX9-2M-40-120V | 40 | 120 |
| CJX9-2M-40-240V | 40 | 240 |
| CJX9-3S-30-24V | 30 | 24 |
| CJX9-3S-30-120V | 30 | 120 |
| CJX9-3S-30-240V | 30 | 240 |
| CJX9-3M-40-24V | 40 | 24 |
| CJX9-3M-40-120V | 40 | 120 |
| CJX9-3M-40-240V | 40 | 240 |
| CJX9-2S-50-240V | 50 | 24 |
| CJX9-3G-50-120C | 50 | 120 |
| CJX9-3G-50-240V | 50 | 240 |
| CJX9-3F-60-24V | 60 | 24 |
| CJX9-3A-60-120V | 60 | 120 |
| CJX9-3A-60-240V | 60 | 240 |
