DS Current Transformers

Tel：+0086.577.61566899

Address：No#221,Wei 17 ROAD,Economic Develop Zone YueQing CITY ZHEJIANG PROVINCE ,CHINA

Intro: Technical data Specification:ModelRatel current(A)Primary/SecondaryBusbar Hole DimensionRated Burden(VA)Accuracy classRated VoltageRated FrequencyDSM-20B50/5A-200/5A1.5-31.0660V50/60HzDSM-2050/5A-200/5A20×10mm1.5-31.0660V50/60HzDSM-3050/5A-200/5A20×10mm1.5-31.0660V50/6 …

Detail

Messages

Product Detail:

Technical data& Specification:

Model	Ratel current(A)Primary/Secondary	Busbar Hole Dimension	Rated Burden(VA)	Accuracy class	Rated Voltage	Rated Frequency
DSM-20B	50/5A-200/5A		1.5-3	1.0	660V	50/60Hz
DSM-20	50/5A-200/5A	20×10mm	1.5-3	1.0	660V	50/60Hz
DSM-30	50/5A-200/5A	20×10mm	1.5-3	1.0	660V	50/60Hz
DSM-30	50/5A-300/5A	30×10mm	2.5-5	1.0	660V	50/60Hz
DS-40	150/5A-800/5A	40×10mm	5-10	1.0	660V	50/60Hz
DS-60	400/5A-1000/5A	60×10mm	10	1.0	660V	50/60Hz
DS-100	800/5A-3000/5A	100×10mm	5	1.0	660V	50/60Hz
