Yueqing long road electric co.,Ltd
Low Voltage Fuse Bases
Product Detail:
| Types | The model No for corresponing fuse | Rate voltage(V) | Rate current(A) | Weight(g) |
| RT16-000 | RT16-000 RT16-00 NT000 NT00 NH00C NH00 | 690 | 160 | 193 |
| Types | The model No for corresponing fuse | Rate voltage(V) | Rate current(A) | Weight(g) |
| RT16-0 | RT16-0 NT0 NH0 | 690 | 160 | 295 |
| Types | The model No for corresponing fuse | Rate voltage (V) | Rate current(A) | Weight(g) |
| RT16-1 | RT16-1 NT1 NH1 | 690 | 250 | 550 |
| RT16-2 | RT16-2 NT2 NH2 | 690 | 400 | 770 |
| RT16-3 | RT16-3 NT3 NH3 | 690 | 630 | 965 |
| Types | The model No for corresponing fuse | Rate voltage(V) | Rate current(A) | Weight(g) | Dimension(mm) | ||||
| A1 | A2 | B1 | H1 | H2 | |||||
| NT1S | RT16-1 NT1 NH1 | 660 | 250 | 604 | 175 | 200 | 50 | 38 | 82 |
| NT2S | RT16-2 NT2 NH2 | 660 | 400 | 1006 | 200 | 230 | 64 | 54 | 104 |
| NT3S | NT16-3 NT2 NH2 | 660 | 630 | 1200 | 210 | 250 | 64 | 54 | 120 |
| Types | The model No for corresponing fuse | Rate voltage(V) | Rate current(A) | Weight(g) |
| NH00 | RT16-000/00 NT000/00 | 660 | 160 | 170 |
| Types | The model No for corresponing fuse | Rate voltage(V) | Rate current | Weight(g) |
| NH00-3J | RT16-000/00 NT000/00 | 660 | 160 | 170 |
| Types | The model No for corresponing fuse | Rate voltage(V) | Rate current(A) | Weight(g) |
| NH00-3J | RT16-000/00 NT000/00 | 660 | 160 | 170 |
| Types | The model No for corresponing fuse | Rate voltage(V) | Rate current(A) | Weight(g) |
| NH4S | RT16-4 NT4 NH4 | 660 | 1000 | 3250 |
| Types | The model No for corresponing fuse | Rate voltage(V) | Rate current(A) | Weight(g) |
| NH00-3J | RT16-2 NT2 NH2 | 660 | 400 | 3600 |
| Types | The model No for corresponing fuse | Rate voltage(V) | Rate current(A) | Weight(g) | Dimension(mm) | |||
| A1 | A2 | B1 | H1 | |||||
| RT0-100 | RTO-100 | 400 | 100 | 545 | 180 | 160 | 55 | 73 |
| RT0-200 | RTO-200 | 400 | 200 | 760 | 200 | 175 | 60 | 85 |
| RT0-300 | RTO-300 | 400 | 400 | 1065 | 220 | 190 | 70 | 95 |
| Types | The model No for corresponing fuse | Rate voltage(V) | Rate current(A) | Weight(g) |
| RT0-600 | RTO-600 | 400 | 600 | 1760 |
| Types | The model No for corresponing fuse | Rate voltage(V) | Rate current(A) | Weight(g) |
| RT0-1000 | RT0-1000 | 400 | 1000 | 3800 |
| Types | The model No for corresponing fuse | Rate voltage(V) | Rate current(A) | Weight(g) | Figure |
| NH0 | RT16-0 NT0 | 660 | 160 | 294 | Fig1 |
| NH1 | NT16-1 NT1 | 660 | 250 | 502 | Fig2 |
| NH2 | NT16-2 NT2 | 660 | 400 | 526 | Fig3 |
| Types | The model No for corresponing fuse | Rate voltage(V) | Rate current(A) | Weight(g) | Figure |
| NH3 | RT16-3 NT3 | 660 | 630 | 762 | Fig4 |
| NH00S1 | NT16-000/00 NT00C/00 | 660 | 160 | 240 | Fig5 |
| NH00S2 | NT16-000/00 NT00C/00 | 660 | 160 | 296 | Fig6 |
| Types | The model No for corresponing fuse | Rate voltage(V) | Rate current(A) | Weight(g) | Figure |
| NT0S | NH0 NT0 NT16-0 | 660 | 160 | 32 | Fig7 |
| RT16-4 | RT16-4 NT4 NH4 | 690 | 1000 | 3400 | Fig8 |
| RT0-50 | RTO-50 | 400 | 50 | 190 | Fig9 |
