Yueqing long road electric co.,Ltd
Power Inverter

Power Inverter

Category：- Inverter

Tel：+0086.577.61566899

Address：No#221,Wei 17 ROAD,Economic Develop Zone YueQing CITY ZHEJIANG PROVINCE ,CHINA

Intro: ModelA8300A8400A8300UA8400UA8500A8600A8500UA8600UInput voltageDC 12V (DC11-15V)Output voltageAC100-120V, AC220-240VUSB output×DC 5V(Max 500mA)×DC 5V(Max 500mA)Continuous power300W400W300W400W500W600W500W600WPeak power600W800W600W800W1000W1200W1000W1200WOutput frequency60+/-3Hz, 50+/-3HzOutput wavefo …


Detail

Messages

Product Detail:

ModelA8300A8400A8300UA8400UA8500A8600A8500UA8600U
Input voltageDC 12V (DC11-15V)
Output voltageAC100-120V, AC220-240V
USB output×DC 5V(Max 500mA)×DC 5V(Max 500mA)
Continuous power300W400W300W400W500W600W500W600W
Peak power600W800W600W800W1000W1200W1000W1200W
Output frequency60+/-3Hz, 50+/-3Hz
Output waveformModified sine wave
NO load current draw<0.45A
Low voltage alarm activationDC10.2-10.8V
Under voltage shutdownDC9.2-9.8V
Over voltage shutdownDC15-16V
Overload protection440W±5%540W±5%440W±5%540W±5%640W±5%750W±5%640W±5%650W±5%
Thermal protection>65˚C
Fuses intermal40A35A+20A40A35A+20A35A×240A×235A×240A×2
ModelA8800A810000A812000A815000A820000A825000A830000
Input voltageDC 12V (DC11-15V)
Output voltageAC100-120V, AC220-240V
Continuous power800W1000W1200W1500W2000W2500W2800W
Peak power1600W2000W2400W3000W4000W5000W6000W
Output frequency60+/-3Hz, 50+/-3Hz
Output waveformModified sine wave
NO load current draw<0.45A
Low voltage alarm activationDC10.2-10.8V
Under voltage shutdownDC9.2-9.8V
Over voltage shutdownDC15-16V
Overload protection940W±5%1200W±5%1400W±5%1700W±5%2300W±5%2800W±5%3200W±5%
tdermal protection>65˚C
Fuses internal25A×435A×435A×435A×620A×1230A×1235A×12
